Hollyland Syscom 421S 2-to-1 Multi-Cam Transmitter and Control System wireless video system

Hollyland Syscom 421S 2-to-1 Multi-Cam Transmitter and Control System wireless video system

Hollyland Syscom 421S is a wireless video and audio transmission system for multi-camera production. It transmits the signal from up to two cameras to a single receiver and is suited to productions that require PTZ control and tally information.

Two camera signals on one receiver

The system supports up to 1080p60 video signals via SDI and HDMI connections. The receiver features two SDI/HDMI outputs, one for each transmitter, allowing the signal to be routed to a monitor or vision mixer.

Directing and tally for production environment

The receiver can be connected to a LAN, allowing control signals to be transmitted from the control panel to the transmitters. This enables the control of PTZ cameras and the transmission of tally data during production.

Displays and power supply for field use

The transmitters and receiver feature an OLED screen, allowing you to see things such as the resolution, transmission channel, signal strength, and battery status. The transmitters feature an L-series battery mount, the receiver has a V-mount battery mount, and both have a 2-pin power input for longer operating times.

Main features

• Wireless video and audio transmission system for up to two cameras
• One receiver processes the signals of two transmitters
• Support for 1080p60 signals via SDI and HDMI inputs
• On the receiver, two SDI/HDMI outputs for a monitor or vision mixer
• LAN connection for transmitting control signals from the control panel to the transmitters
• PTZ control and tally data transmission supported
• OLED displays show the resolution, channel, signal strength and battery status
• Transmitters feature an L-series battery mount and the receiver a V-mount battery mount

Technical specifications

• Product code: 114367
• Manufacturer's part number: HL-SYSCOM 421S-2TX1R
• 6970758742924
• Touch screen: no
• Video format: HDMI 480p60–1080p60, SDI 720p–1080p60
• Resolution: up to 1080p60
• Transmission range: 548 m with line of sight
• Latency: 0.07 s
• Audio-visual connections: SDI and HDMI
• Outputs: 2 × SDI/HDMI on the receiver
